Description
The NET 150 PP Trickle Packs Grid Cooling Fill is an advanced, high-performance solution designed for counterflow and crossflow cooling towers in demanding industrial environments. Engineered from durable polypropylene, this fill media excels in applications with poor water quality—such as those found in power plants, refineries, chemical production facilities, steel mills, and food processing operations. Its robust design allows for long-term operation even in the presence of suspended solids, oils, and chemical contaminants.
Trickle Grid Fill, particularly the NET 150 series, is known for its structural strength and thermal efficiency. It can be installed in field-erected or package-type towers and is walkable without the need for temporary support boards. This significantly simplifies maintenance operations. The design allows for effective flushing with high-pressure water jets, maintaining long-term cleanliness and performance.
The NET 150 fill provides optimized pressure drop characteristics, ensuring efficient heat transfer while minimizing airflow resistance. With a high level of impact resistance and chemical stability, it maintains performance under high-temperature conditions and harsh operating environments. Brentwood offers this product in a variety of pack sizes, allowing for flexible integration into both new and retrofit cooling tower designs.
Key Benefits:
- Ideal for poor-water quality applications containing suspended solids and oils
- Constructed from polypropylene for superior chemical and thermal resistance
- Designed for use in both counterflow and crossflow cooling towers
- Walkable surface without the need for temporary platforms
- Easy to clean using high-pressure water jets
- High mechanical stability and impact resistance
- Long service life and environmentally friendly construction
- Cost-effective and easy to install
Technical Specifications:
| Model | Pack Size (D/W/L) (inches) | Max Span (inches) | Sheet Size (inches) | Sheets Per Skid | Skid Dimensions (L/W/H) (inches) | Approx. Skid Weight (lbs) |
|---|---|---|---|---|---|---|
| NET 150 | 17.72 / 11.85 / 35.75 | 24 | 17.72 | 1701 | 53.9 x 36.2 x 96.1 | 891 |
Material: Polypropylene (PP)
Color: Typically black or grey (custom colors available on request)
Fire Rating: Available upon request depending on regulatory requirements
Installation: Modular design enables rapid installation with minimal labor
Applications:
- Power generation cooling systems
- Oil & gas refineries
- Chemical and petrochemical plants
- Steel manufacturing cooling circuits
- Food and beverage processing facilities
Whether you’re upgrading an aging cooling system or designing a new installation, the NET 150 PP Trickle Packs Grid Cooling Fill delivers the thermal performance, mechanical durability, and serviceability required for industrial-scale cooling under challenging conditions.
